xmlrpc for c and c++(xmlrpc-c)をWindows10, openFrameworks環境で使う

XML-RPCは古いインターフェースですが、Pythonの標準ライブラリでサーバーが簡単に作れるので、C++からPythonを呼び出したい時など、時と場合によっては便利に使えます。以前libxmlrpc++を紹介したことがありますが、今回のはxmlrpc for c and c++(xmlrpc-c)です。違いは、xmlrpc-cは非同期(Asynch≒non-blocking)に対応していること(ただしインターフェースは洗練されていない)です。

CMakeサポート版のフォーク xmlrpc-c

github.com
個人のgraugansさんが作られたもので、5か月ぐらい前が最終更新のタイムスタンプです。
HTTP用の外部ライブラリが必要で、

  • Curl
  • Libwww
  • Wininet

から選んで使います。Curlが推奨されていますが、Windowsでは標準で使えるWininetでも特に問題は感じません。ここでは、Wininetを使うことにします。

CMakeLists.txtを編集

どのライブラリを選択してもfindCurlを必ず呼んでここで引っかかってしまうので、コメントアウトしてしまいます。乱暴なことをしていますので、何があっても責任取れません。自分で判断して使ってください。

#find_package(CURL ${tmp})
#ensc_set_bool(MUST_BUILD_CURL_CLIENT ${CURL_FOUND} "Set if Curl client transport shall be built")

あとは普通にcmakeでconfigureとgenerateしてプロジェクトを作ってください。

build

普通にビルドをすると半分ぐらいビルドできますが、半分ぐらいエラーで落ちます。適当にCMakeLists.txtを適当に編集したためにMUST_BUILD_CURL_CLIENTの定義が抜けてしまっているためです。次のように修正します。
transport_config.h

/* -*- c -*- */
#define MUST_BUILD_WININET_CLIENT	1
#define MUST_BUILD_LIBWWW_CLIENT	0
#define MUST_BUILD_CURL_CLIENT		0 //////

bin, include, libを集める

出力ファイルは何故かあちこちにバラバラに配置されています。

cライブラリは、build/src/ReleaseもしくはDebugに.dllと.libがあります。
c++ライブラリは、build/src/cpp/Release もしくはDebugに.dllと.libファイルがあります。
xmlrpc_util.dllとxmlrpc_util.libは、build/lib/libutil/ReleaseもしくはDebugにあります。

includeファイルは、include/xmlrpc-cにあります。
config.hは、build/include/xmlrpc-cにあります。

自分の都合の良いように、適当なフォルダの中にそれぞれ放り込んでください。

サンプルプログラム

たとえば非同期クライアントを動かしてみます。Curlを使っていませんので、Curl対応の関数を読んでいるところをwininet用関数に置き換えます。
https://sourceforge.net/p/xmlrpc-c/code/HEAD/tree/trunk/examples/cpp/asynch_client.cpp

//xmlrpc_c::clientXmlTransport_curl myTransport;
xmlrpc_c::clientXmlTransport_wininet myTransport;

Resultが構造体だったりArrayだったりするときのデータ受け取り方法

xmlrpc++はとてもスマートに直感的にかけたのですが、xmlrpc-cは残念ながらいまいちです。返り値が構造体の場合は、下記のようにデータを解釈させます。

構造体受信の例

jntという名前のdouble型arrayが入っている構造体の受信例です。

	string const serverUrl("http://192.168.0.11:4321");
	string const methodName("get_joint");

	xmlrpc_c::clientSimple myClient;
	xmlrpc_c::value result;

	myClient.call(serverUrl, methodName, "", &result);

	xmlrpc_c::value_struct s(result.cValue());
	xmlrpc_c::value_array a(s.cvalue()["jnt"]);
	for (int i = 0; i < 6; i++) {
		joint[i] = xmlrpc_c::value_double(a.cvalue()[i]);
	}

構造体送信の例

	xmlrpc_c::clientXmlTransport_wininet myTransport;
	xmlrpc_c::client_xml myClient(&myTransport);

	string const methodName("move_joint");

	xmlrpc_c::carray a;
	for (int i = 0; i < 6; i++) {
		a.push_back(xmlrpc_c::value_double(joint[i]));
	}

	xmlrpc_c::cstruct s;
	s.insert(std::make_pair<std::string, xmlrpc_c::value>("", xmlrpc_c::value_array(a)));

	xmlrpc_c::paramList sampleAddParms1;
	sampleAddParms1.add(xmlrpc_c::value_struct(s));

	xmlrpc_c::rpcPtr rpc1P(methodName, sampleAddParms1);
	string const serverUrl("http://192.168.0.11:4321");

	xmlrpc_c::carriageParm_curl0 myCarriageParm(serverUrl);
	rpc1P->start(&myClient, &myCarriageParm);


	myClient.finishAsync(xmlrpc_c::timeout(100));

今日のノートPC

アマゾン専売のMSIの軽量14インチノート。11万円ぐらいでGeForceMX150搭載。自宅用はもうこれで良いね。
[asin:B07D8PJBGS:detail]
[asin:B07FB27SNB:detail]

自分用読むべき論文メモ 2018年07月版


RealSenseD400シリーズと組み合わせてKinect2の人体認識の代替に使えそうな有料ライブラリ。30$/センサーなので十分安い。

qiita.com
画像処理を高速化できる(2~10倍ぐらい見込める)Halide言語について。

今日のコンピュータビジョン

各章、とてもよくまとまっていて読みやすい。

メモ:OpenGLの描画結果のデプスバッファから距離情報を復元する方法

OpenGLの描画結果のデプス値を単位を直して画像データとして取得するサンプル。詳細は[1]を参照のこと。
1. glReadPixelsでデプスバッファのデータを読み込み
2. nearClipとfarClipでデプス値を正規化
3. 上下反転されているので入れ替え

ofPixels pix;
pix.allocate(ofGetWidth(), ofGetHeight(), OF_IMAGE_COLOR);
double depth_scale = 1000.0;

std::vector<float> depth_image;
depth_image.resize(ofGetWidth() * ofGetHeight());

glReadPixels(0, 0, ofGetWidth(), ofGetHeight(), GL_DEPTH_COMPONENT, GL_FLOAT, depth_image.data());

double z_near = cam.getNearClip();
double z_far = cam.getFarClip();

for (int i = 0; i < ofGetHeight(); i++) {
	for (int j = 0; j < ofGetWidth(); j++) {
		double z_depth = 2.0 * z_near * z_far /
			(z_far + z_near - (2.0 * (double)depth_image[(ofGetHeight() - i - 1) * ofGetWidth() + j] - 1.0) *
			(z_far - z_near));
			uint16_t p = (uint16_t)std::min(std::round(depth_scale * z_depth), (double)INT16_MAX);

			pix.setColor(j, i, ofColor((float)p / 255, (float)p%255, 0));
	}
}

[1] Open3D Visualization
github.com

今日の座布団

安い椅子での長時間の座り仕事で、お尻が痛くなります。そんな時にはこれ。ちょっと暑いけど。

Open3DのReconstruction systemをC++に移植(その3-1 integrate_scene)

integrate_scene.h

#pragma once

// Open3D: www.open3d.org
// The MIT License (MIT)
// See license file or visit www.open3d.org for details

#include <Core/Core.h>
#include <IO/IO.h>
#include <Visualization/Visualization.h>

void integrate_scene_main(std::string path_dataset, std::string path_intrinsic);

integrate_scene.cpp

#include "integrate_scene.h"
#include "common_py.h"

#include <Eigen/Dense>

extern std::string template_global_posegraph_optimized;
extern std::string template_fragment_posegraph_optimized;
extern std::string template_global_mesh;
extern three::PinholeCameraIntrinsic read_pinhole_camera_intrinsic(const std::string &filename);

void scalable_integrate_rgb_frames(std::string path_dataset, three::PinholeCameraIntrinsic intrinsic, bool draw_result = false)
{
	std::shared_ptr<std::vector<std::string>> color_files;
	std::shared_ptr<std::vector<std::string>> depth_files;
	get_rgbd_file_lists(color_files, depth_files, path_dataset);
	int n_files = static_cast<int>(color_files->size());
	int n_frames_per_fragment = 100;
	int n_fragments = static_cast<int>(std::ceil(float(n_files) / n_frames_per_fragment));
	double voxel_length = 3.0 / 512.0;
	double sdf_trunc = 0.04;
	bool with_color = true;
	three::ScalableTSDFVolume volume = three::ScalableTSDFVolume(voxel_length,
		sdf_trunc, with_color);

	three::PoseGraph pose_graph_fragment;
	three::ReadIJsonConvertibleFromJSON(path_dataset + template_global_posegraph_optimized, pose_graph_fragment);

	for (int fragment_id = 0; fragment_id < pose_graph_fragment.nodes_.size(); fragment_id++) {
		three::PoseGraph pose_graph_rgbd;
		std::string filename(path_dataset + template_fragment_posegraph_optimized);
		sprintf((char*)filename.data(), (path_dataset + template_fragment_posegraph_optimized).c_str(), fragment_id);
		three::ReadIJsonConvertibleFromJSON(filename, pose_graph_rgbd);

		for (int frame_id = 0; frame_id < pose_graph_rgbd.nodes_.size(); frame_id++) {
			int frame_id_abs = fragment_id * n_frames_per_fragment + frame_id;
			std::cout << "Fragment " << fragment_id << " / " << n_fragments - 1 << " :: integrate rgbd frame " << frame_id_abs << " (" << frame_id + 1 << " of "
				<< pose_graph_rgbd.nodes_.size() << ")." << std::endl;
			std::shared_ptr<three::Image> color = std::make_shared<three::Image>();
			std::shared_ptr<three::Image> depth = std::make_shared<three::Image>();
			three::ReadImage((*color_files)[frame_id_abs], *color);
			three::ReadImage((*depth_files)[frame_id_abs], *depth);
			double depth_trunc = 3.0;
			bool convert_rgb_to_intensity = false;
			std::shared_ptr<three::RGBDImage> rgbd = std::make_shared<three::RGBDImage>();
			rgbd = three::CreateRGBDImageFromColorAndDepth(*color, *depth,
				1000.0, depth_trunc, convert_rgb_to_intensity);
			Eigen::Matrix4d pose = pose_graph_fragment.nodes_[fragment_id].pose_ * pose_graph_rgbd.nodes_[frame_id].pose_;
			volume.Integrate(*rgbd, intrinsic, pose.inverse());
		}
	}

	std::shared_ptr<three::TriangleMesh> mesh = volume.ExtractTriangleMesh();
	mesh->ComputeVertexNormals();
	if (draw_result) {
		three::DrawGeometries({ mesh });
	}

	std::string mesh_name = path_dataset + template_global_mesh;
	three::WriteTriangleMeshToPLY(mesh_name, *mesh, false, true);
}

void integrate_scene_main(std::string path_dataset, std::string path_intrinsic)
{
	std::cout << "integrate the whole RGBD sequence using estimated camera pose" << std::endl;
	std::cout << "path to the dataset " << path_dataset << std::endl;
	std::cout << "path to the RGBD camera intrinsic " << path_intrinsic << std::endl;

	three::PinholeCameraIntrinsic intrinsic;
	if (!path_intrinsic.empty()) {
		intrinsic = read_pinhole_camera_intrinsic(path_intrinsic);
	}
	else {
		intrinsic = three::PinholeCameraIntrinsic(
			three::PinholeCameraIntrinsicParameters::PrimeSenseDefault);
	}
	scalable_integrate_rgb_frames(path_dataset, intrinsic);
}

実行結果

Python版の出力サイズと微妙に異なるので、何か間違えているのかも。
f:id:cvl-robot:20180629235805p:plain

Open3DのReconstruction systemをC++に移植(その2-1 register_fragment)

register_fragments.h

#pragma once

// Open3D: www.open3d.org
// The MIT License (MIT)
// See license file or visit www.open3d.org for details

#include <Core/Core.h>
#include <IO/IO.h>
#include <Visualization/Visualization.h>

void register_fragments_main(std::string path_dataset_);

register_fragments.cpp

#include "register_fragments.h"
#include "common_py.h"
#include "optimize_posegraph.h"

#include <Core/Registration/PoseGraph.h>
#include <Core/Registration/FastGlobalRegistration.h>
#include <Core/Registration/ColoredICP.h>

#include <Eigen/Dense>

/////////////////////////
// some global parameters for the global registration
/////////////////////////

extern int n_frames_per_fragment;
extern int n_keyframes_per_n_frame;


//////////////////////////
// file related
//////////////////////////

extern std::string folder_fragment;
extern std::string template_fragment_posegraph;
extern std::string template_fragment_posegraph_optimized;
extern std::string template_fragment_mesh;
extern std::string folder_scene;
extern std::string template_global_posegraph;
extern std::string template_global_posegraph_optimized;
extern std::string template_global_mesh;

std::tuple<std::shared_ptr<three::PointCloud>, std::shared_ptr<three::Feature>> preprocess_point_cloud(three::PointCloud& pcd)
{
	std::shared_ptr<three::PointCloud> pcd_down = std::make_shared<three::PointCloud>();
	pcd_down = three::VoxelDownSample(pcd, 0.05);
	double radius = 0.1;
	int max_nn = 30;
	three::EstimateNormals(*pcd_down,
		three::KDTreeSearchParamHybrid(radius, max_nn));
	radius = 0.25;
	max_nn = 100;
	std::shared_ptr<three::Feature> pcd_fpfh = std::make_shared<three::Feature>();
	pcd_fpfh = three::ComputeFPFHFeature(*pcd_down,
		three::KDTreeSearchParamHybrid(radius, max_nn));
	return std::tuple<std::shared_ptr<three::PointCloud>, std::shared_ptr<three::Feature>>(pcd_down, pcd_fpfh);
}

std::tuple<bool, three::RegistrationResult> register_point_cloud_fpfh(three::PointCloud& source, three::PointCloud& target,
	three::Feature& source_fpfh, three::Feature& target_fpfh)
{
	double maximum_correspondence_distance = 0.07;
	three::RegistrationResult result = three::FastGlobalRegistration(
		source, target, source_fpfh, target_fpfh,
		three::FastGlobalRegistrationOption(1.399999999999911, false, true, maximum_correspondence_distance));
	if (result.transformation_.trace() == 4.0) {
		return std::tuple<bool, three::RegistrationResult>(false, Eigen::Matrix4d::Identity());
	}
	return std::tuple<bool, three::RegistrationResult>(true, result);
}

void draw_registration_result(three::PointCloud& source, three::PointCloud& target, Eigen::Matrix4d transformation)
{
	std::shared_ptr<three::PointCloud> source_temp = std::make_shared<three::PointCloud>(source);
	std::shared_ptr<three::PointCloud> target_temp = std::make_shared<three::PointCloud>(target);
	source_temp->PaintUniformColor(Eigen::Vector3d(1., 0.706, 0.));
	target_temp->PaintUniformColor(Eigen::Vector3d(0., 0.651, 0.929));
	source_temp->Transform(transformation);
	three::DrawGeometries({ source_temp, target_temp });
}

std::tuple<bool, Eigen::Matrix4d> compute_initial_registartion(int s, int t, three::PointCloud& source_down, three::PointCloud& target_down,
	three::Feature& source_fpfh, three::Feature& target_fpfh, std::string path_dataset, bool draw_result = false)
{
	Eigen::Matrix4d transformation;
	if (t == s + 1) { // odomety case
		std::cout << "Using RGBD odometry" << std::endl;
		std::string filename(path_dataset + template_fragment_posegraph_optimized);
		sprintf((char*)filename.data(), (path_dataset + template_fragment_posegraph_optimized).c_str(), s);
		three::PoseGraph pose_graph_frag;
		three::ReadIJsonConvertibleFromJSON(filename, pose_graph_frag);
		int n_nodes = static_cast<int>(pose_graph_frag.nodes_.size());
		transformation = pose_graph_frag.nodes_[n_nodes - 1].pose_.inverse();
		std::cout << pose_graph_frag.nodes_[0].pose_ << std::endl;
		std::cout << transformation << std::endl;
	}
	else { // loop closure case
		std::cout << "register_point_cloud_fpfh" << std::endl;
		auto ret = register_point_cloud_fpfh(
			source_down, target_down,
			source_fpfh, target_fpfh);
		bool success_ransac = std::get<0>(ret);
		three::RegistrationResult result_ransac = std::get<1>(ret);
		if (!success_ransac) {
			std::cout << "No reasonable solution. Skip this pair" << std::endl;
			return std::tuple<bool, Eigen::Matrix4d>(false, Eigen::Matrix4d::Identity());
		}
		else {
			transformation = result_ransac.transformation_;
		}
		std::cout << transformation << std::endl;
	}

	if (draw_result) {
		draw_registration_result(source_down, target_down,
			transformation);
	}
	return std::tuple<bool, Eigen::Matrix4d>(true, transformation);
}

// colored pointcloud registration
// This is implementation of following paper
// J. Park, Q.-Y. Zhou, V. Koltun,
// Colored Point Cloud Registration Revisited, ICCV 2017
std::tuple<Eigen::Matrix4d, Eigen::Matrix6d> register_colored_point_cloud_icp(three::PointCloud& source, three::PointCloud& target,
	Eigen::Matrix4d init_transformation = Eigen::Matrix4d::Identity(),
	std::vector<double> voxel_radius = std::vector<double>({ 0.05, 0.025, 0.0125 }), std::vector<int> max_iter = std::vector<int>({ 50, 30, 14 }),
	bool draw_result = false)
{
	Eigen::Matrix4d current_transformation = init_transformation;
	three::RegistrationResult result_icp;

	for (int scale = 0; scale < max_iter.size(); scale++) { // multi-scale approach
		int iter = max_iter[scale];
		double radius = voxel_radius[scale];
		std::cout << "radius " << radius << std::endl;
		std::shared_ptr<three::PointCloud> source_down = three::VoxelDownSample(source, radius);
		std::shared_ptr<three::PointCloud> target_down = three::VoxelDownSample(target, radius);
		double radius_n = radius * 2;
		int max_nn = 30;
		three::EstimateNormals(*source_down, three::KDTreeSearchParamHybrid(radius_n, max_nn));
		if (0) { // print(np.assarray(source_down.normals))
			for (int i = 0; i < source_down->normals_.size(); i++) {
				std::cout << source_down->normals_[i] << " ";
			}
			std::cout << std::endl;
		}
		three::EstimateNormals(*target_down, three::KDTreeSearchParamHybrid(radius_n, max_nn));
		double relative_fitness = 1e-6;
		double relative_rmse = 1e-6;
		int max_iteration = iter;
		result_icp = three::RegistrationColoredICP(*source_down, *target_down,
			radius, current_transformation,
			three::ICPConvergenceCriteria(relative_fitness, relative_rmse, max_iteration));
		current_transformation = result_icp.transformation_;
	}
	Eigen::Matrix6d information_matrix = three::GetInformationMatrixFromPointClouds(
		source, target, 0.07, result_icp.transformation_);
	if (draw_result) {
		draw_registration_result_original_color(source, target,
			result_icp.transformation_);
	}
	return std::tuple<Eigen::Matrix4d, Eigen::Matrix6d>(result_icp.transformation_, information_matrix);
}

std::tuple<bool, Eigen::Matrix4d, Eigen::Matrix6d> local_refinement(int s, int t, three::PointCloud& source, three::PointCloud& target,
	Eigen::Matrix4d transformation_init, bool draw_result = false)
{
	Eigen::Matrix4d transformation;
	Eigen::Matrix6d information;
	if (t == s + 1) { // odometry case
		std::cout << "register_point_cloud_icp" << std::endl;
		std::vector<double> voxel_radius({ 0.0125 });
		std::vector<int> max_iter({ 30 });
		auto ret = register_colored_point_cloud_icp(
			source, target, transformation_init,
			voxel_radius, max_iter);
		transformation = std::get<0>(ret);
		information = std::get<1>(ret);
	}
	else { // loop closure case
		std::cout << "register_colored_point_cloud" << std::endl;
		auto ret = register_colored_point_cloud_icp(
			source, target, transformation_init);
		transformation = std::get<0>(ret);
		information = std::get<1>(ret);
	}

	bool success_local = false;
	if ((information(5, 5) / std::min(source.points_.size(), target.points_.size())) > 0.3) {
		success_local = true;
	}
	if (draw_result) {
		draw_registration_result_original_color(
			source, target, transformation);
	}
	return std::tuple<bool, Eigen::Matrix4d, Eigen::Matrix6d>(success_local, transformation, information);
}

std::tuple<Eigen::Matrix4d, three::PoseGraph> update_odometry_posegraph(int s, int t, Eigen::Matrix4d transformation, Eigen::Matrix6d information,
	Eigen::Matrix4d odometry, three::PoseGraph& pose_graph)
{
	std::cout << "Update PoseGraph" << std::endl;
	if (t == s + 1) { // odometry case
		odometry = transformation * odometry;
		Eigen::Matrix4d odometry_inv = odometry.inverse();
		pose_graph.nodes_.push_back(three::PoseGraphNode(odometry_inv));
		bool uncertain = false;
		pose_graph.edges_.push_back(
			three::PoseGraphEdge(s, t, transformation,
				information, uncertain));
	}
	else { // loop closure case
		bool uncertain = true;
		pose_graph.edges_.push_back(
			three::PoseGraphEdge(s, t, transformation,
				information, uncertain));
	}
	return std::tuple<Eigen::Matrix4d, three::PoseGraph>(odometry, pose_graph);
}

void register_point_cloud(std::string path_dataset, std::vector<std::string>& ply_file_names, bool draw_result = false)
{
	three::PoseGraph pose_graph = three::PoseGraph();
	Eigen::Matrix4d odometry = Eigen::Matrix4d::Identity();
	pose_graph.nodes_.push_back(three::PoseGraphNode(odometry));
	Eigen::Matrix6d info = Eigen::Matrix6d::Identity();

	int n_files = static_cast<int>(ply_file_names.size());
	for (int s = 0; s < n_files; s++) {
		for (int t = s + 1; t < n_files; t++) {
			std::shared_ptr<three::PointCloud> source = std::make_shared<three::PointCloud>();
			std::shared_ptr<three::PointCloud> target = std::make_shared<three::PointCloud>();
			std::cout << "reading " << ply_file_names[s] << " ...";
			bool ret = three::ReadPointCloud(ply_file_names[s], *source);
			std::cout << "reading " << ply_file_names[s] << " ...";
			ret = three::ReadPointCloud(ply_file_names[t], *target);
			auto ret_s = preprocess_point_cloud(*source);
			std::shared_ptr<three::PointCloud> source_down = std::get<0>(ret_s);
			std::shared_ptr<three::Feature> source_fpfh = std::get<1>(ret_s);
			auto ret_t = preprocess_point_cloud(*target);
			std::shared_ptr<three::PointCloud> target_down = std::get<0>(ret_t);
			std::shared_ptr<three::Feature> target_fpfh = std::get<1>(ret_t);
			auto ret_c = compute_initial_registartion(
				s, t, *source_down, *target_down,
				*source_fpfh, *target_fpfh, path_dataset, draw_result);
			bool success_global = std::get<0>(ret_c);
			Eigen::Matrix4d transformation_init = std::get<1>(ret_c);
			if (!success_global) {
				continue;
			}
			//std::cout << "success global" << s << " , " << t << std::endl;
			auto ret_l = local_refinement(s, t, *source, *target,
				transformation_init, draw_result);
			bool success_local = std::get<0>(ret_l);
			Eigen::Matrix4d transformation_icp = std::get<1>(ret_l);
			Eigen::Matrix6d information_icp = std::get<2>(ret_l);
			if (!success_local) {
				continue;
			}
			//std::cout << "success local" << s << " , " << t << std::endl;
			auto ret_u = update_odometry_posegraph(s, t,
				transformation_icp, information_icp,
				odometry, pose_graph);
			odometry = std::get<0>(ret_u);
			// pose_graph = std::get<1>(ret_u);
			// std::cout << pose_graph << std::endl;
		}
	}

	// three::WritePoseGraph(path_dataset + template_global_posegraph, pose_graph);
	three::WriteIJsonConvertibleToJSON(path_dataset + template_global_posegraph, pose_graph);
}

void register_fragments_main(std::string path_dataset) {
	three::SetVerbosityLevel(three::VerbosityLevel::VerboseDebug);

	std::shared_ptr<std::vector<std::string>> ply_file_names = get_file_list(path_dataset + folder_fragment, ".ply");
	make_folder(path_dataset + folder_scene);
	register_point_cloud(path_dataset, *ply_file_names);
	optimize_posegraph_for_scene(path_dataset);
}

Open3DのReconstruction systemをC++に移植(その1-3 make_fragment)

openFrameworksの呼び出し部分の例と実行結果。

ofApp.cpp

// Open3D: www.open3d.org
// The MIT License (MIT)
// See license file or visit www.open3d.org for details

#include "ofApp.h"

#include "make_fragments.h"

#pragma comment(lib, "Open3D.lib")
//#pragma comment(lib, "Core.lib")
//#pragma comment(lib, "IO.lib")
//#pragma comment(lib, "Visualization.lib")
#pragma comment(lib, "jsoncpp.lib")
#pragma comment(lib, "jpeg.lib")
#pragma comment(lib, "tinyfiledialogs.lib")
#pragma comment(lib, "png.lib")

#pragma comment(lib, "opencv_core400.lib")
#pragma comment(lib, "opencv_features2d400.lib")
#pragma comment(lib, "opencv_highgui400.lib")
#pragma comment(lib, "opencv_calib3d400.lib")

//--------------------------------------------------------------
void ofApp::setup() {
	make_fragments_main("D:/workspace/016", "");
	register_fragments_main("D:/workspace/016");
	integrate_scene_main("D:/workspace/016", "");
}

//--------------------------------------------------------------
void ofApp::update() {

}

//--------------------------------------------------------------
void ofApp::draw() {

}

//--------------------------------------------------------------
void ofApp::keyPressed(int key) {

}

//--------------------------------------------------------------
void ofApp::keyReleased(int key) {

}

//--------------------------------------------------------------
void ofApp::mouseMoved(int x, int y) {

}

//--------------------------------------------------------------
void ofApp::mouseDragged(int x, int y, int button) {

}

//--------------------------------------------------------------
void ofApp::mousePressed(int x, int y, int button) {

}

//--------------------------------------------------------------
void ofApp::mouseReleased(int x, int y, int button) {

}

//--------------------------------------------------------------
void ofApp::mouseEntered(int x, int y) {

}

//--------------------------------------------------------------
void ofApp::mouseExited(int x, int y) {

}

//--------------------------------------------------------------
void ofApp::windowResized(int w, int h) {

}

//--------------------------------------------------------------
void ofApp::gotMessage(ofMessage msg) {

}

//--------------------------------------------------------------
void ofApp::dragEvent(ofDragInfo dragInfo) {

}

実行結果

f:id:cvl-robot:20180628170109p:plain
f:id:cvl-robot:20180628170118p:plain
一つのセグメントの処理が一巡すると下のようなメッセージが表示されて/fragmentsフォルダの下に次の3つのファイルが生成されます。

[GlobalOptimizationLM] Optimizing PoseGraph having 100 nodes and 118 edges.
Line process weight : 44793.956121
[Initial ] residual : 2.438500e+04, lambda : 2.543928e+02
[Iteration 00] residual : 5.961908e+03, valid edges : 118, time : 0.005 sec.
[Iteration 01] residual : 3.527648e+03, valid edges : 118, time : 0.005 sec.
[Iteration 02] residual : 3.525901e+03, valid edges : 118, time : 0.005 sec.
[Iteration 03] residual : 3.525896e+03, valid edges : 118, time : 0.005 sec.
Current_residual - new_residual < 1.000000e-06 * current_residual
[GlobalOptimizationLM] total time : 0.025 sec.
[GlobalOptimizationLM] Optimizing PoseGraph having 100 nodes and 118 edges.
Line process weight : 44793.956121
[Initial ] residual : 3.525896e+03, lambda : 2.608960e+02
Current_residual - new_residual < 1.000000e-06 * current_residual
[GlobalOptimizationLM] total time : 0.003 sec.
CompensateReferencePoseGraphNode : reference : 0

fragment_000.json (posegarph)
fragment_000.ply (mesh)
fragment_optimized_000.json (最適化したposegraph)

f:id:cvl-robot:20180628170753p:plainf:id:cvl-robot:20180628170758p:plain
f:id:cvl-robot:20180628170802p:plainf:id:cvl-robot:20180628170806p:plain

今日のそうめん

もっともっと大きなのもオススメ。
store.shopping.yahoo.co.jp

Open3DのReconstruction systemをC++に移植(その1-2 make_fragment)

make_fragmentのc++移植の続き

opencv_pose_estimation.h

#pragma once

// Open3D: www.open3d.org
// The MIT License (MIT)
// See license file or visit www.open3d.org for details

#include <Core/Core.h>
#include <IO/IO.h>
#include <Visualization/Visualization.h>

#include <opencv/cv.h>

std::tuple<bool, Eigen::Matrix4d> pose_estimation(three::RGBDImage& source_rgbd_image, three::RGBDImage& target_rgbd_image,
	three::PinholeCameraIntrinsic intrinsic, bool debug_draw_correspondences);

std::tuple<bool, Eigen::Matrix4d, std::vector<int>&> estimate_3D_transform_RANSAC(std::vector<Eigen::Vector3d>& pts_xyz_s, std::vector<Eigen::Vector3d>& pts_xyz_t);

std::tuple<Eigen::Matrix3d, Eigen::Vector3d> estimate_3D_transform(std::vector<Eigen::Vector3d>& input_xyz_s, std::vector<Eigen::Vector3d>& input_xyz_t);

Eigen::Vector3d get_xyz_from_pts(cv::Point2d pts_row, cv::Mat& depth, double px, double py, double focal);

Eigen::Vector3d get_xyz_from_uv(double u, double v, double d, double px, double py, double focal);

opencv_pose_estimation.cpp

// following original code is tested with OpenCV 3.2.0 and Python2.7

#include "opencv_pose_estimation.h"

#include <random>
#include <Eigen/SVD>
#include <Eigen/LU>

#include <opencv/cv.h>
#include <opencv2/features2d.hpp>
#include <opencv2/highgui.hpp>
#include <opencv2/calib3d.hpp>


std::tuple<bool, Eigen::Matrix4d> pose_estimation(three::RGBDImage& source_rgbd_image, three::RGBDImage& target_rgbd_image,
	three::PinholeCameraIntrinsic pinhole_camera_intrinsic, bool debug_draw_correspondences)
{
	bool success = false;
	Eigen::Matrix4d trans = Eigen::Matrix4d::Identity();

	// transform double array to unit8 array
	cv::Mat color_cv_s_f(source_rgbd_image.color_.height_, source_rgbd_image.color_.width_, CV_32FC1);
	cv::Mat color_cv_t_f(target_rgbd_image.color_.height_, target_rgbd_image.color_.width_, CV_32FC1);
	memcpy((void*)(color_cv_s_f.data), (void*)(&source_rgbd_image.color_.data_[0]), source_rgbd_image.color_.width_ * source_rgbd_image.color_.height_ * source_rgbd_image.color_.num_of_channels_ * source_rgbd_image.color_.bytes_per_channel_);
	memcpy((void*)(color_cv_t_f.data), (void*)(&target_rgbd_image.color_.data_[0]), target_rgbd_image.color_.width_ * target_rgbd_image.color_.height_ * target_rgbd_image.color_.num_of_channels_ * target_rgbd_image.color_.bytes_per_channel_);

	cv::Mat color_cv_s;
	cv::Mat color_cv_t;
	color_cv_s_f.convertTo(color_cv_s, CV_8UC1, 255);
	color_cv_t_f.convertTo(color_cv_t, CV_8UC1, 255);

	int nfeatures = 100;
	float scaleFactor = 1.2f;
	int nlevels = 8;
	int edgeThreshold = 31;
	int firstLevel = 0;
	int WTA_K = 2;
	int scoreType = cv::ORB::HARRIS_SCORE;
	int patchSize = 31;
	cv::Ptr<cv::ORB> orb = cv::ORB::create(nfeatures, scaleFactor, nlevels, edgeThreshold,
		firstLevel, WTA_K, scoreType, patchSize); // to save time

	cv::Mat des_s, des_t;
	std::vector<cv::KeyPoint> kp_s, kp_t;
	orb->detect(color_cv_s, kp_s);
	orb->detect(color_cv_t, kp_t);
	orb->compute(color_cv_s, kp_s, des_s);
	orb->compute(color_cv_t, kp_t, des_t);
	if ((kp_s.size() == 0) || (kp_t.size() == 0)) {
		return std::tuple<bool, Eigen::Matrix4d>(success, trans);
	}

	cv::Ptr<cv::DescriptorMatcher> matcher = cv::DescriptorMatcher::create("BruteForce-Hamming");
	std::vector<cv::DMatch> dmatch;
	dmatch.clear();
	std::vector<cv::DMatch> dmatch12, dmatch21;

	matcher->match(des_s, des_t, dmatch12);
	matcher->match(des_t, des_s, dmatch21);
	// CrossCheck = True
	for (size_t i = 0; i < dmatch12.size(); ++i)
	{
		cv::DMatch m12 = dmatch12[i];
		cv::DMatch m21 = dmatch21[m12.trainIdx];

		if (m21.trainIdx == m12.queryIdx)
			dmatch.push_back(m12);
	}

	int count = static_cast<int>(dmatch.size());

	std::vector<cv::Point2d> pts_s;
	std::vector<cv::Point2d> pts_t;
	pts_s.clear();
	pts_t.clear();
	for (int i = 0; i < dmatch.size(); i++) {
		pts_t.push_back(kp_t[dmatch[i].trainIdx].pt);
		pts_s.push_back(kp_s[dmatch[i].queryIdx].pt);
	}

	// inlier points after initial BF matching
	if (debug_draw_correspondences) {
		cv::Mat result;
		drawMatches(color_cv_s, kp_s, color_cv_t, kp_t, dmatch, result);
		cv::imshow("Initial BF matching", result);
		cv::waitKey(1);
		// draw_correspondences();
	}

	double focal_input = (pinhole_camera_intrinsic.intrinsic_matrix_(0, 0) +
		pinhole_camera_intrinsic.intrinsic_matrix_(1, 1)) / 2.0;
	double pp_x = pinhole_camera_intrinsic.intrinsic_matrix_(0, 2);
	double pp_y = pinhole_camera_intrinsic.intrinsic_matrix_(1, 2);

	// Essential matrix is made for masking inliers
	std::vector<cv::Point2i> pts_s_int;
	std::vector<cv::Point2i> pts_t_int;
	for (int i = 0; i < pts_s.size(); i++) {
		pts_s_int.push_back(cv::Point2i(pts_s[i].x + 0.5, pts_s[i].y + 0.5));
	}
	for (int i = 0; i < pts_t.size(); i++) {
		pts_t_int.push_back(cv::Point2i(pts_t[i].x + 0.5, pts_t[i].y + 0.5));
	}
	cv::Mat E, mask;
	double focal = focal_input;
	cv::Point2d pp(pp_x, pp_y);
	int method = cv::RANSAC;
	double prob = 0.999;
	double threshold = 1.0;
	E = cv::findEssentialMat(pts_s_int, pts_t_int, focal,
		pp, method, prob, threshold, mask);
	if (mask.empty()) {
		return std::tuple<bool, Eigen::Matrix4d>(success, trans);
	}

	// inlier points after 5pt algorithm
	if (debug_draw_correspondences) {

	}

	// make 3D correspondences
	cv::Mat depth_s(source_rgbd_image.depth_.height_, source_rgbd_image.depth_.width_, CV_32FC1);
	cv::Mat depth_t(source_rgbd_image.depth_.height_, source_rgbd_image.depth_.width_, CV_32FC1);
	memcpy((void*)(depth_s.data), (void*)(&source_rgbd_image.depth_.data_[0]), source_rgbd_image.depth_.width_ * source_rgbd_image.depth_.height_ * source_rgbd_image.depth_.num_of_channels_ * source_rgbd_image.depth_.bytes_per_channel_);
	memcpy((void*)(depth_t.data), (void*)(&target_rgbd_image.depth_.data_[0]), target_rgbd_image.depth_.width_ * target_rgbd_image.depth_.height_ * target_rgbd_image.depth_.num_of_channels_ * target_rgbd_image.depth_.bytes_per_channel_);
	std::vector<Eigen::Vector3d> pts_xyz_s;
	std::vector<Eigen::Vector3d> pts_xyz_t;
	pts_xyz_s.clear();
	pts_xyz_t.clear();
	int cnt = 0;
	for (int i = 0; i < pts_s.size(); i++) {
		if (mask.at<int>(i)) {
			pts_xyz_s.push_back(get_xyz_from_pts(pts_s[i], depth_s,
				pp_x, pp_y, focal_input));
			pts_xyz_t.push_back(get_xyz_from_pts(pts_t[i], depth_t,
				pp_x, pp_y, focal_input));
			cnt = cnt + 1;
		}
	}

	auto ret = estimate_3D_transform_RANSAC(pts_xyz_s, pts_xyz_t);
	success = std::get<0>(ret);
	trans = std::get<1>(ret);
	std::vector<int> inlier_id_vec = std::get<2>(ret);

	if (debug_draw_correspondences)
	{

	}

	return std::tuple<bool, Eigen::Matrix4d>(success, trans);
}

std::tuple<bool, Eigen::Matrix4d, std::vector<int>&> estimate_3D_transform_RANSAC(std::vector<Eigen::Vector3d>& pts_xyz_s, std::vector<Eigen::Vector3d>& pts_xyz_t)
{
	int max_iter = 1000;
	double max_distance = 0.05;
	int n_sample = 5;
	int n_points = static_cast<int>(pts_xyz_s.size());
	Eigen::Matrix4d Transform_good = Eigen::Matrix4d::Identity();
	int max_inlier = n_sample;
	std::vector<int> inlier_vec_good;
	inlier_vec_good.clear();
	bool success = false;

	if (n_points < n_sample) {
		return std::tuple<bool, Eigen::Matrix4d, std::vector<int>&>(success, Transform_good, inlier_vec_good);
	}

	for (int i = 0; i < max_iter; i++) {
		std::vector<Eigen::Vector3d> sample_xyz_s;
		std::vector<Eigen::Vector3d> sample_xyz_t;

		// sampling
		std::random_device rnd;
		std::mt19937 mt(rnd());
		std::uniform_int_distribution<> randn(0, n_points);
		for (int j = 0; j < n_sample; j++) {
			int rand_idx = randn(mt);
			sample_xyz_s.push_back(pts_xyz_s[rand_idx]);
			sample_xyz_t.push_back(pts_xyz_t[rand_idx]);
		}
		auto ret = estimate_3D_transform(sample_xyz_s, sample_xyz_t);
		Eigen::Matrix3d R_approx = std::get<0>(ret);
		Eigen::Vector3d t_approx = std::get<1>(ret);

		// evaluation
		std::vector<Eigen::Vector3d> diff_mat;
		for (int j = 0; j < n_points; j++) {
			diff_mat.push_back(pts_xyz_t[j] - (R_approx * pts_xyz_s[j] + t_approx));
		}
		std::vector<double> diff;
		for (int j = 0; j < n_points; j++) {
			diff.push_back(diff_mat[j].norm());
		}
		int n_inlier = 0;
		for (int j = 0; j < diff.size(); j++) {
			double diff_iter = diff[j];
			if (diff_iter < max_distance) {
				n_inlier += 1;
			}
		}

		// note: diag(R_approx) > 0 prevents ankward transformation between
		// RGBD pair of relatively small amount of baseline.
		if ((n_inlier > max_inlier) && (R_approx.determinant() != 0.) &&
			(R_approx(0, 0) > 0) && (R_approx(1, 1) > 0) && (R_approx(2, 2) > 0))
		{
			for (int j = 0; j < 3; j++) {
				for (int k = 0; k < 3; k++) {
					Transform_good(j, k) = R_approx(j, k);
				}
				Transform_good(j, 3) = t_approx(j);
			}
			// std::cout << "Transform_good = \n" << Transform_good << std::endl;
			max_inlier = n_inlier;

			inlier_vec_good.clear();
			for (int id_iter = 0; id_iter < n_points; id_iter++) {
				double diff_iter = diff[id_iter];
				if (diff_iter < max_distance) {
					inlier_vec_good.push_back(id_iter);
				}
			}
			success = true;
		}
	}

	return std::tuple<bool, Eigen::Matrix4d, std::vector<int>&>(success, Transform_good, inlier_vec_good);
}

// signular value decomposition approach
// based on the description in the sec 3.1.2 in
// http::/graphics.stanford.edu/~smr/ICP/comparison/eggert_comparison_mva97.pdf
std::tuple<Eigen::Matrix3d, Eigen::Vector3d> estimate_3D_transform(std::vector<Eigen::Vector3d>& input_xyz_s, std::vector<Eigen::Vector3d>& input_xyz_t)
{
	// compute H
	int n_points = static_cast<int>(input_xyz_s.size());
	Eigen::Vector3d mean_s(0., 0., 0.);
	for (int i = 0; i < input_xyz_s.size(); i++) {
		mean_s += input_xyz_s[i];
	}
	mean_s /= n_points;
	Eigen::Vector3d mean_t(0., 0., 0.);
	for (int i = 0; i < input_xyz_t.size(); i++) {
		mean_t += input_xyz_t[i];
	}
	mean_t /= n_points;

	Eigen::MatrixXd xyz_diff_s(3, input_xyz_s.size());
	for (int i = 0; i < input_xyz_s.size(); i++) {
		for (int j = 0; j < 3; j++) {
			xyz_diff_s(j, i) = input_xyz_s[i](j) - mean_s(j);
		}
	}
	Eigen::MatrixXd xyz_diff_t(3, input_xyz_t.size());
	for (int i = 0; i < input_xyz_t.size(); i++) {
		for (int j = 0; j < 3; j++) {
			xyz_diff_t(j, i) = input_xyz_t[i](j) - mean_t(j);
		}
	}

	Eigen::MatrixXd H;
	H.resize(3, 3);
	H = xyz_diff_s * xyz_diff_t.transpose();

	// solve system
	Eigen::JacobiSVD<Eigen::MatrixXd> svd(H, Eigen::ComputeFullU | Eigen::ComputeFullV);
	Eigen::Matrix3d R_approx = svd.matrixV().transpose() * svd.matrixU().transpose();
	if (R_approx.determinant() < 0.0) {
		double det = (svd.matrixU() * svd.matrixV()).determinant();
		Eigen::Matrix3d D = Eigen::Matrix3d::Identity();
		D(2, 2) = det;
		R_approx = svd.matrixU() * (D * svd.matrixV());
	}
	Eigen::Vector3d t_approx = mean_t - (R_approx * mean_s);
	return std::tuple<Eigen::Matrix3d, Eigen::Vector3d>(R_approx, t_approx);
}

Eigen::Vector3d get_xyz_from_pts(cv::Point2d pts_row, cv::Mat& depth, double px, double py, double focal)
{
	double u = pts_row.x;
	double v = pts_row.y;
	int u0 = int(u);
	int v0 = int(v);
	int height = depth.rows;
	int width = depth.cols;
	// bilinear depth interpolation
	if ((u0 > 0) && (u0 < width - 1) && (v0 > 0) && (v0 < height - 1)) {
		double up = pts_row.x - u0;
		double vp = pts_row.y - v0;
		double d0 = depth.at<double>(v0, u0);
		double d1 = depth.at<double>(v0, u0 + 1);
		double d2 = depth.at<double>(v0 + 1, u0);
		double d3 = depth.at<double>(v0 + 1, u0);
		double d = (1 - vp) * (d1 * up + d0 * (1 - up)) + vp * (d3 * up + d2 * (1 - up));
		return get_xyz_from_uv(u, v, d, px, py, focal);
	}
	return Eigen::Vector3d(0., 0., 0.);
}

Eigen::Vector3d get_xyz_from_uv(double u, double v, double d, double px, double py, double focal)
{
	double x, y;
	if (focal != 0.) {
		x = (u - px) / focal + d;
		y = (v - py) / focal + d;
	}
	else {
		x = 0.;
		y = 0.;
	}
	return Eigen::Vector3d(x, y, d).transpose();
}

optimize_posegraph.h

#pragma once

// Open3D: www.open3d.org
// The MIT License (MIT)
// See license file or visit www.open3d.org for details

#include <Core/Core.h>
#include <IO/IO.h>
#include <Visualization/Visualization.h>

void optimize_posegraph_for_fragment(std::string path_dataset, int fragment_id);
void optimize_posegraph_for_scene(std::string path_dataset);

optimize_posegraph.cpp

#include "optimize_posegraph.h"

#include <Core/Registration/PoseGraph.h>
#include <Core/Registration/GlobalOptimizationMethod.h>
#include <Core/Registration/GlobalOptimizationConvergenceCriteria.h>
#include <Core/Registration/GlobalOptimization.h>

#include <IO/ClassIO/PoseGraphIO.h>

extern std::string template_fragment_posegraph;
extern std::string template_fragment_posegraph_optimized;
extern std::string template_global_posegraph;
extern std::string template_global_posegraph_optimized;

void run_posegraph_optimization(std::string pose_graph_name, std::string pose_graph_optimized_name,
	double max_correspondence_distance, double preference_loop_closure)
{
	// to display messages from global optimization
	three::SetVerbosityLevel(three::VerbosityLevel::VerboseDebug);
	const three::GlobalOptimizationMethod & method = three::GlobalOptimizationLevenbergMarquardt();
	const three::GlobalOptimizationConvergenceCriteria &criteria = three::GlobalOptimizationConvergenceCriteria();
	const three::GlobalOptimizationOption &option = three::GlobalOptimizationOption(max_correspondence_distance,
		0.25,
		preference_loop_closure,
		0);
	three::PoseGraph pose_graph;
	//three::ReadPoseGraph(pose_graph_name, pose_graph); // Read PoseGraph failed: unknown file extension.
	three::ReadIJsonConvertibleFromJSON(pose_graph_name, pose_graph);
	three::GlobalOptimization(pose_graph, method, criteria, option);
	//three::WritePoseGraph(pose_graph_optimized_name, pose_graph); // Write PoseGraph failed: unknown file extension.
	three::WriteIJsonConvertibleToJSON(pose_graph_optimized_name, pose_graph);
	three::SetVerbosityLevel(three::VerbosityLevel::VerboseError);
}

void optimize_posegraph_for_fragment(std::string path_dataset, int fragment_id)
{
	std::string pose_graph_name(path_dataset + template_fragment_posegraph);
	sprintf((char*)pose_graph_name.data(), (path_dataset + template_fragment_posegraph).c_str(), fragment_id);
	std::string pose_graph_optimized_name(path_dataset + template_fragment_posegraph_optimized);
	sprintf((char*)pose_graph_optimized_name.data(), (path_dataset + template_fragment_posegraph_optimized).c_str(), fragment_id);

	run_posegraph_optimization(pose_graph_name, pose_graph_optimized_name,
		0.07,
		0.1);
}

void optimize_posegraph_for_scene(std::string path_dataset)
{
	std::string pose_graph_name(path_dataset + template_global_posegraph);
	std::string pose_graph_optimized_name(path_dataset +
		template_global_posegraph_optimized);
	double max_correspondence_distance = 0.07;
	double preference_loop_closure = 2.0;
	run_posegraph_optimization(pose_graph_name, pose_graph_optimized_name,
		max_correspondence_distance,
		preference_loop_closure);
}
注意点
  • ファイル入出力だけにopenFrameworksの関数を使っています。ofDirなど。代替のライブラリがあれば、そちらに書き換えてください。
  • ReadPoseGraph, WritePoseGraphなどファイルの入出力のユーティリティ関数において、拡張子の照合が上手くいかなくて正しく動作しません。代わりに、拡張子を特定してWriteJsonConvertibleToJSONなどを直接呼んでいます。
  • デバッグ用の表示関数を省略しています。つまり、ちゃんとデバッグできていない可能性があります。
  • Eigenを使い慣れてないせいで無駄にstd::vectorと組み合わせたり、汚い書き方していますがご容赦を。もしくはきれいに書き換えてください。

今日のそうめん

そうめんは古くなるほどおいしくなるそうなので、もっと大きなやつもオススメ。
store.shopping.yahoo.co.jp
